How to Debug a Oil Type Mold Temperature Controller?

Hengde Company, a renowned name in the industrial temperature control realm, has been committed to providing high quality mold temperature controllers for years. Our products are widely applied across various industries, characterized by their reliability, precision, and advanced technology. With a professional R & D team and excellent after - sales service, we ensure that every customer can make the most of our mold temperature controllers. Now, let's explore the professional debugging process of our mold temperature controllers.

Debugging Steps of the Oil Type Mold Temperature Controller

1. Preparation

Before commencing the debugging, ensure the availability of a stable power supply and high quality thermal oil.

2. Power Connection

Push the air switch and then turn on the power button. In case the air switch fails to be pushed up, check if the emergency stop button on the controller panel is pressed. If so, rotate the emergency stop button to its normal position.

After turning on the power button, if the oil type mold temperature controller alarms, it is likely due to a phase - reversal issue. Immediately turn off the power supply and swap any two of the three incoming power lines. Once the phase - reversal problem is resolved, the controller can start normally.

3. Oil Filling

After starting the machine, the oil mold temperature machine will trigger an oil shortage alarm. Gradually add thermal oil, until the entire pipeline is filled with oil and the oil shortage alarm in the oil tank ceases. Be cautious not to over fill the oil tank. As the oil heats up, the tank will release gas. Excessive oil may cause the gas to force the oil out of the tank.

After oil filling, carefully inspect all pipelines of the oil mold temperature machine for any oil leaks. Once the pressure shown on the pressure gauge of the oil temperature machine stabilizes, the heating process can be initiated.

4. Heating

Set the temperature on the controller for heating. Initially, set the temperature to 90℃ and closely monitor the stability of the pressure gauge. If the pressure gauge remains stable, it is safe to directly set the temperature to the required operating temperature.

Precautions

1. Prior to starting the machine, always double - check whether the emergency stop button on the oil mold temperature controller panel is in the released state. A pressed emergency stop button will prevent the air switch from being closed.
2. During the heating process, if there is a significant difference between the oil outlet temperature and the oil return temperature, with the oil outlet temperature rising rapidly, it is highly likely that the filter is blocked. Before further heating, remove and clean the filter to ensure normal oil circulation.
3. If the oil mold temperature controller alarms for oil - shortage or lack of media, it may be caused by poor contact of the liquid level sensor (the cylindrical tube adjacent to the oil tank). Usually, a slight adjustment of the sensor can solve this problem. If the liquid level alarm function is not required, simply unplug the wire above the sensor.

After the debugging process is completed, it is crucial to record all the debugging parameters and the operating status of the mold temperature controller accurately. Compile these records into a detailed debugging report. Once the oil mold temperature controller is put into formal operation, regular maintenance and inspections should be carried out at fixed intervals. This ensures that the controller always operates in an optimal condition, providing reliable temperature control for your production processes.

At Hengde Company, we not only offer top - tier mold temperature controllers but also comprehensive support throughout the product lifecycle. Our professional team is always ready to assist you, ensuring that your investment in our products brings long - term benefits and efficient production.

Choose Hengde,Choose Perfect Mold Temperature Controller！
