230kW Water Cooled Chillers Completed for WPC Door Panel Extrusion

Hengde has completed the production of two HC-230WS Water Cooled Chillers for a customer in Iraq. The two units are designed for a WPC door panel and frame extrusion production line and are currently awaiting the customer's final confirmation before packaging.

With a cooling capacity of 230kW per unit, these industrial chillers are configured for continuous cooling requirements in extrusion production. The equipment combines a Bitzer compressor, environmentally friendly R407C refrigerant, PLC digital control, and multiple automatic protection functions to support stable and reliable operation.

Project Specifications

Built for WPC Door Panel & Frame Extrusion

WPC door panels and frames are commonly produced through extrusion processes that require consistent temperature control. During continuous production, process heat needs to be removed efficiently to help maintain stable operating conditions.

For this project, Hengde supplied two 230kW water cooled chillers to provide the required cooling capacity for the customer's WPC extrusion application.

Compared with air cooled equipment, a Water Cooled Chiller can be suitable for industrial facilities where a cooling water system is available and higher-capacity cooling is required. The HC-230WS is designed around this type of industrial cooling requirement.

Bitzer Compressor and R407C Refrigerant

The HC-230WS is equipped with a Bitzer compressor, a well-known refrigeration component brand widely used in industrial and commercial refrigeration applications.

The chiller uses R407C refrigerant, which is commonly used in air-conditioning and refrigeration equipment. Combined with an efficient refrigeration circuit and water cooled condenser design, the unit is configured to provide stable cooling performance for continuous industrial operation. Other key features include:

• PLC Digital Controller for convenient operation and monitoring
• Stainless Steel Water Pump for improved durability
• High-Efficiency System for reliable industrial cooling
• Low-Noise Operation for a more comfortable working environment
• Automatic Protection System for safer operation
• High Pressure Protection
• Low Pressure Protection
• Overload Protection
• Flow Protection

These functions help the chiller respond to different operating conditions and provide multiple layers of protection during production.

Final Confirmation Before Packaging

The two HC-230WS chillers have now completed production. Before the equipment is packed, Hengde is waiting for the customer's final confirmation to make sure the configuration and equipment details meet the project requirements.

This final confirmation is an important step for customized industrial equipment, especially when the chiller needs to be integrated into an existing extrusion production line. Once confirmed, the units will proceed to the next stage of packaging and shipment preparation for Iraq.

Customized Industrial Chillers from Hengde

Every production line has different requirements for cooling capacity, temperature control, installation conditions, components, and operating functions. A standard chiller configuration may not always be the most suitable solution.

Hengde manufactures Industrial Chillers, Water Cooled Chillers, and Air Cooled Chillers and can customize equipment according to the customer's actual application requirements. Cooling capacity, compressor configuration, control system, pump selection, protection functions, and other technical specifications can be considered during the equipment design process.

For this Iraq project, the 230kW Water Cooled Chiller was configured specifically for WPC door panel and frame extrusion. If you are looking for a chiller for extrusion, plastics processing, or another industrial application, contact Hengde with your cooling capacity and process requirements, and our team can help you develop a suitable customized cooling solution.
